Display Glass inspection

Dimensional

Capabilities and Tolerances

The size capability and tolerance to which a specification can be held are influenced by the cutting and edging process. The above-listed size and tolerance capabilities are a guideline only. These tolerances are used as defaults for the listed sizes and shapes. Tighter tolerances may be available upon request.

Shape Min/Max Size Tolerance
Rectangle Min 5mm +/- .2mm
  Max 1000mm +/- .5MM
Diameter Min 7mm +/- .2mm
  Max 500mm +/- .5MM
Custom Min 5mm +/- .2mm
  Max 1000mm +/- .5MM
Shape Min/Max Size Tolerance
Rectangle Min 10mm +/- .2mm
  Max 1000mm +/- .5MM
Diameter Min 25mm +/- .2mm
  Max 500mm +/- .5MM
Custom Min TBD TBD
  Max TBD TBD
Shape Min/Max Size Tolerance
Rectangle Min 25mm +/- .1mm
  Max 500mm +/- .2MM
Diameter Min 25mm +/- .1mm
  Max 300mm +/- .2MM
Custom Min 25mm +/- .1mm
  Max 300mm +/- .2MM
Shape Min/Max Size Tolerance
Rectangle Min 25mm +/- .25mm
  Max 350mm ++/- .25mm
Diameter Min 25mm +/- .25mm
  Max 350mm +/- .25mm
Custom Min 25mm +/- .25mm
  Max 350mm +/- .2mm
